Walk In Cycle Climate Temperature Stability Chamber 70dB For Battery Safety

Name: Walk In Cycle Climate Temperature Stability Chamber 70dB For Battery Safety
Brand: DGBELL
Price: 1 USD

Brand Name : DGBELL

Model Number : BTHW-3m³-C

Certification : CE/ISO

Place of Origin : China

MOQ : 1 Set

Price : Negotiation

Payment Terms : T/T, Western Union, D/P, L/C, D/A, MoneyGram

Supply Ability : 500 Sets per Month

Delivery Time : Negotiation

Packaging Details : Each set protected with resin fiber and PP film, then put into Strong wooden case with operation manual inside.

Keywords : Walk in Temperatuer Cycle Climate Stability Test Equipment for Battery Safety

Internal Dimension : W2000 X H1500 X D1000mm (Can be customized）

External Dimension : W2500 X H3540 X D1500mm

Temperature Range : -40℃ ~ +150℃(Can be customized）

Humidity Range : 20%RH-98%RH

Temperature Fluctuation : ±0.5℃

Humidity Fluctuation : ±2.5％RH

Temperature Deviation : ≤±2.0℃

Humidity Deviation : A)>75%RH:≤+2,-3%RH，B)<75%RH:≤±5%RH。

Temperature Uniformity : ≤2.0℃

Maximum Load : 100KG

Contact Now

Walk in Temperatuer Cycle Climate Stability Test Chamber for Battery Safety

Walk In Cycle Climate Temperature Stability Chamber 70dB For Battery Safety

Standards

IEC 62133
UN 38.3
UL 1642

Technical Parameters

Model	BTHW-3m³-C
Effective Volume	3m³
Internal Dimension	W2000 X H1500 X D1000mm (Can be customized)
External Dimension	W2500 X H3540 X D1500mm(including the motor height for the top of the chamber)
Temperature Range	-40℃ ~ +150℃(Can be customized)
Humidity Range	20%RH-98%RH (Limit temperature section, see the regional figure )
Temperature Fluctuation	±0.5℃
Humidity Fluctuation	±2.5％RH
Temperature Deviation	≤±2.0℃
Humidity Deviation	A)>75%RH:≤+2,-3%RH,B)<75%RH:≤±5%RH.
Temperature Uniformity	≤2.0℃
Heating Rate	0.1~1.2℃/min(From -40℃ up to +80℃ ,average, linear with load)
Cooling time	0.1~1.2℃/min(From -40℃ up to +80℃ ,average, linear with load)
Temperature Overshoot	≤2℃
Maximum Load	100KG
Constant Max. Heating Load	No
Noise	≤70dB(A Level)
External Material	Galvanized sheet with high temperature electrostatic resin coating at both sides.
Internal Material	1.2 mm thickness SUS# 304 heat and cold resistant stainless steel with seal welding.
Control Method	Touch screen programmable PLC, with USB interface, with RJ485 interface can be connected to computer controlling, special network control software, convenient remote monitoring, data acquisitioning.
Compressor	Semi-Hermetic Compressors BOCK (Germany)
Observe Window	With 3-layers vacuum glass observation window on the door(W430mm*H580mm) ; Door frame with electric heat function (auto adjustable), anti-frosting, anti-condensing devices, ensures clear observation of the specimen under testing
Power Supply	AC 380V 50HZ 27KW
Auxiliary Function	Explosion-proof pressure relief device, explosion-proof chain, mobile phone alarm device, networking, smoke exhaust device, fire extinguishing device, etc.
